| Tempat asal: | Cina |
| Nama merek: | BRANDO |
| Sertifikasi: | CE |
| Nomor model: | C113443, C113444 |
| Kuantitas min Order: | 1 set |
|---|---|
| Harga: | Dapat dinegosiasikan |
| Kemasan rincian: | Kantong plastik, Kotak, Karton, Pallet |
| Waktu pengiriman: | 4 sampai 7 hari kerja |
| Syarat-syarat pembayaran: | L/C,T/T,Paypal,Western Union |
| Menyediakan kemampuan: | 100000 set per bulan |
| Nama Produk: | Diafragma katup pulsa | Kode pemesanan: | C113443, C113444, C113-443, C113-444 |
|---|---|---|---|
| Bahan diafragma: | TPE, NBR, FKM | 1 set: | 1pc Diafragma, 1pc Musim Semi |
| Port Katup Pulsa yang Dipasang: | 3/4 '', 1 '' | Model katup pulsa yang dipasang: | SCG353A043, SCG353A044, G353A041, G353A042 |
| Menyoroti: | ASCO Diaphragm C113443,ASCO Diaphragm C113444,ASCO Pulse Valve Diaphragm |
||
C113443 C113444 Diaphragm Repair Kit For SCG353A043 SCG353A044 ASCO Pulse Valve
C113443, C113444, C113-443, C113-444 Diaphragm (Membrane) for ASCO pulse valve SCG353A043, SCG353A044, G353A041, G353A042; TPE, NBR, Viton are all available; Pulse valve, also called diaphragm valve acts as a "switch" for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.
Ordering Number of Diaphragm For ASCO Pulse Valve:
|
Valve Port Size
|
Pulse Valve Model
|
Diaphragm Model
|
Diaphragm Material
(FKM is also available)
|
|
3/4''
|
SCG353A043
|
C113444
|
TPE (White), NBR (Black)
|
|
1''
|
SCG353A044
|
||
|
3/4''
|
SCG353-052
|
||
|
1''
|
SCG353-053
|
||
|
3/4''
|
SGG353A043
|
||
|
1''
|
SGG353A044
|
||
|
3/4''
|
SGG353-052
|
||
|
1''
|
SGG353-053
|
||
|
1 1/2''
|
SCG353A047
|
C113827
|
NBR
|
|
SGG353A065
|
|||
|
2''
|
SCG353A050
|
C113685, C113686
|
NBR
|
|
2 1/2''
|
SCG353A051
|
||
|
3''
|
SCXE353.060
|
C123432, C123433
|
NBR
|
|
SCG353D060
|
|||
|
3/4''
|
G3530A41
|
C113443
|
NBR
|
|
1''
|
G353A042
|
||
|
3/4''
|
G353-055
|
||
|
1''
|
G353-056
|
||
|
1 1/2''
|
G353A045
|
C113825
|
NBR
|
|
G353-066
|
|||
|
1 1/2''
|
G353A046
|
C113826
|
NBR
|
|
G353A063
|
|||
|
2''
|
G353A048
|
C113684
|
NBR
|
|
2 1/2''
|
G353A049
|
Main Dimension of C113443, C113444 Diaphragm:
![]()
Product Video of C113443, C113444 Membrane:
Pictures of Pulse Valve Diaphragm Production:
![]()
More Related Products For you to choose:
| Threaded Type | Remote Pilot Type | Straight Through Type | Submerged Type |
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
