NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves

NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves

  • NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves
  • NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves
NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves
Detail produk:
Tempat asal: Cina
Nama merek: Ningbo BRANDO
Sertifikasi: None
Nomor model: 2W200
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1 set
Harga: Dapat dinegosiasikan
Kemasan rincian: kotak batin, karton, palet
Waktu pengiriman: 7 hari kerja
Syarat-syarat pembayaran: T/T, Western Union, Paypal
Menyediakan kemampuan: 100000pcs per bulan
Kontak
Detil Deskripsi produk
Nama Produk: Diafragma Katup Solenoid Air Bahan Diafragma: NBR, EPDM, Viton
Port Katup Pulsa yang Dipasang: 3/4'' Model katup pulsa yang dipasang: 2W200-20, 2S200-20
Menyoroti:

Diaphragm For 2W Brass Solenoid Valve

,

2S200-20 Solenoid Valve Membrane

,

Water Solenoid Valve Diaphragm 3/4''

NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves



Diaphragm ( Membrane ) for 3/4'' solenoid valve 2W200-20, 2S200-20. Diaphragm type solenoid valves are most commonly associated with 2-way solenoid valves. They generally consist of a rubber diaphragm which moves up or down within a valve body. This promotes an opening or closing against a hard seat, thereby changing the state of the solenoid valve. In direct acting or diaphragm control valves, the media pressure has no bearing on the position of the diaphragm. It simply changes its state once the solenoid coil is energised and either opens or closes, depending on the specification of the solenoid valve in its resting state (normally closed or normally open).


Ordering Code of Diaphragm For Water Solenoid Valve:

Ordering Code
Fitted Valve Code
Valve Port Size
Material
2W160
2W160-10
3/8''
NBR
2S160-10
2W160-15
1/2''
2S160-15
2W200
2W200-20
3/4''
2S200-20
2W250
2W250-25
1''
2S250-25
2W350
2W350-35
1-1/4''
2S350-35
2W400
2W400-40
1-1/2''
2S400-40
2W500
2W500-50
2''
2S500-50
Tips: EPDM, FKM all available.


Dimension of 3/4'' Water Solenoid Valve Diaphragm:

NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 0

Video of 3/4'' Water Solenoid Valve Diaphragm:


Pictures of Solenoid Valve Membrane Production:

NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 1


More Products For Water Solenoid Valve for you to choose:

NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 2 NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 3
Brass Water Solenoid Valve Stainless Steel Water Solenoid Valve
NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 4 NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 5NBR Diaphragm Kit For 2W200-20 2S200-20 3/4'' Water Solenoid Valves 6
Solenoid Coil Solenoid Armature


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
