Name: 2'' UPVC Anti-Corrosive Solenoid Valve Normally Closed AC220V AC110V DC24V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: FF1U50B50
Price: 25.00 USD
Availability: InStock

Rumah Produk Katup Solenoid Plastik

2'' UPVC Anti-Corrosive Solenoid Valve Normally Closed AC220V AC110V DC24V

Detail produk:

Tempat asal:	NINGBO, Tiongkok
Nama merek:	BRANDO
Sertifikasi:	None
Nomor model:	FF1U50B50

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	200
Harga:	Dapat dinegosiasikan
Kemasan rincian:	kotak batin, karton, palet
Waktu pengiriman:	Perundingan
Syarat-syarat pembayaran:	T/T, Paypal, Western Union
Menyediakan kemampuan:	100000pcs per bulan

Kontak

Detil Deskripsi produk

Fungsi:	2 Way, Biasanya Tertutup	Ukuran Pelabuhan:	Kebakaran minyak nabati
Ukuran lubang:	50mm	Bahan Badan Katup:	UPVC
Bahan Segel:	EPDM, FKM	Rentang Tekanan Kerja:	0.1 sampai 6 bar
Tegangan:	12VDC, 24VDC, 110VAC, 220VAC	Operasi:	Piston Pilot Dioperasikan
Media Kerja:	Kimia, Asam, Alkali, Cairan Korosif, dll
Menyoroti:	UPVC Solenoid Valve 2'' , Corrosion-resistant Solenoid Valve 2'' UPVC , UPVC Anti-corrosive Normally Closed Solenoid Valve DN50

2'' UPVC Anti-Corrosive Solenoid Valve Normally Closed AC220V AC110V DC24V

This is an anti corrosive UPVC solenoid valve, 2'' female threaded port size, 50mm orifice size, 2 way normally closed, piston pilot operated, 0.1 to 6 bar working pressure, can be EPDM or FKM seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.

Product Features:

1. Working Medium: Chemical, Acid, Alkali, Corrosive Liquids
2. Body Material: UPVC
3. Seal Material: EPDM, FKM
4. Port Size: 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''
5. Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm
6. Operation: Piston Pilot Operated
7. Function: 2 Way Normally Closed
8. Working Pressure: 0.1 to 6 bar
9. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Technical Data:

Model No	Orifice Size (mm)	Port Size (inch)	Cv	Working Pressure (bar)	Body Material	Seal Material	Function
FF1U15B04	15	1/2''	4	0.1 to 6	UPVC	EPDM FKM	2 Way NC
FF1U20B06	20	3/4''	5.5	0.1 to 6
FF1U25B25	25	1''	13	0.1 to 6
FF1U32B32	32	1 1/4''	17	0.1 to 6
FF1U40B40	40	1 1/2''	25	0.1 to 6
FF1U50B50	50	2''	40	0.1 to 6

Main Dimension:

2'' UPVC Anti-Corrosive Solenoid Valve Normally Closed AC220V AC110V DC24V 0

Model No	Port	A	B	C	D	E
FF1U15B04	1/2''	74	132	92	63.5	63.5
FF1U20B06	3/4''	80	137	92	63.5	63.5
FF1U25B25	1''	100	147	92	74	74
FF1U32B32	1 1/4''	120	171	94	94	94
FF1U40B40	1 1/2''	130	180	94	94	94
FF1U50B50	2''	172	225	94	155	155
