Name: FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: FDF4A
Price: 65.00 USD
Availability: InStock

Rumah Produk Refrigerasi Solenoid Valve

FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V

Detail produk:

Tempat asal:	Cina
Nama merek:	BRANDO
Sertifikasi:	None
Nomor model:	FDF4A

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	5 buah
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Kotak Dalam, Karton, Palet
Waktu pengiriman:	perundingan
Syarat-syarat pembayaran:	T/T, Western Union, MoneyGram
Menyediakan kemampuan:	100000 BUAH per bulan

Kontak

Detil Deskripsi produk

Nama Produk:	Katup Solenoid Pendingin	Tabung OD (mm):	6.35
Ukuran lubang:	4.0mm	Jenis kabel:	Petunjuk Terbang
Posisi Biasa:	NC (Biasanya Tertutup)	Aktuasi:	Akting langsung
Voltase:	24VDC, 24VAC, 110VAC, 220VAC	Aplikasi:	AC, Pompa Panas, Pembuat Es, Freezer, Pendingin, dll.
Tekanan Operasional Maks:	4,5 mpa
Menyoroti:	FDF4A refrigeration solenoid valve , FDF series refrigeration solenoid valve air conditioning , Sanhua FDF4A Solenoid Valve

FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V

FDF series solenoid valves are direct operated or pilot operated solenoid valves, mainly used in refrigerant control of various devices such as refrigerating and freezing systems, air conditioners and heat pumps.

* Applicable for all common HCFC, HFC refrigerants such as: R22, R134a, R404A, R407C, R410A, R507, R407A/F, R448A/R449A, R452A, R450A/R513A)
* Applicable medium temperature: -30ºC to +120ºC;
* Applicable ambient temperature: -30ºC to +50ºC;
* Relative humidity: below 95%
* Installation position:
1. Liquid, suction and discharge line
2. Coil upwards, coil axis ± 15º tolerance versus vertical axis
3. Flow direction corresponds to the arrow

Technical Data of FDF NC Series Solenoid Valve:

Model	FDF2A94	FDF2.5A06	FDF3A08	FDF4A10	FDF6A58	FDF8A21	FDF11A05	FDF13A07
Actuation	Direct	Pilot
Kv(m³/h)	0.08	0.2	0.26	0.3	0.56	1.29	2.4	3.44
Max. OPD (MPa)	3.4	3.4	3.4	3.4	3.4	2.8	2.8	2.8
Min. OPD (MPa)	0	0.01	0.01	0.01	0.01	0.01	0.02	0.02
MOP (MPa)	4.5
Normal Position	NC
Tube OD (inch)	1/4''	1/4''	5/16''	1/4''	5/16''	3/8''	1/2''	5/8''
Tube OD (mm)	6.35	6.34	7.94	6.35	7.94	9.52	12.7	15.88

Main Dimension of FDF NC Series Solenoid Valve:

FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V 0

Model	Measurement (mm)
Model	L	L1	L2
FDF 2A 94	67	32	34
FDF 2.5A 08	85	38	38
FDF 3A 08	81	35	36
FDF 4A 10	81	35	38
FDF 6A 58	81	35	36
FDF 8A 21	114	62	62
FDF 11A 16	113	61	61
FDF 13A 12	114	62	62

More Refrigeration Solenoid Valves for you to choose:


Danfoss Type Solenoid Valve	Castel Type Solenoid Valve	Sanhua Type Solenoid Valve

More Expansion Valves for you to choose:


Thermal Expansion Valve	Automatic Expansion Valve	Electronic Expansion Valve

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
