Name: 0543 Nass Magnet Type Solenoid Coil 12V 24V DC 110V 220V AC
Brand: Ningbo Brando Hardware Co., Ltd
SKU: BB14542004
Price: 49.10 USD
Availability: InStock

Rumah Produk Coil Katup Solenoid

0543 Nass Magnet Type Solenoid Coil 12V 24V DC 110V 220V AC

Detail produk:

Tempat asal:	NINGBO, Tiongkok
Nama merek:	BRANDO
Sertifikasi:	None
Nomor model:	BB14542004

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	200
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Kotak Dalam, Karton, Palet
Waktu pengiriman:	perundingan
Syarat-syarat pembayaran:	T/T, PayPal, Western Union
Menyediakan kemampuan:	250000 lembar per bulan

Kontak

Detil Deskripsi produk

Nama Produk:	Koil katup solenoid	Voltase:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Kekuatan:	20W, 12W, 13W, 22VA, 15VA	Koneksi:	DIN43650A
Kelas Perlindungan:	IP65	Kelas Isolasi:	F, h
Menyoroti:	Nass Magnet Type Solenoid Coil 24V , 0543 Solenoid Coil 24V , 0543 Solenoid Coil220V

0543 Nass Magnet Type Solenoid Coil 12V 24V DC 110V 220V AC

This solenoid coil is same with Nass Magnet solenoid coil 0543, which is popularly used in Shako solenoid valves, like PU220A, PU225A, SPU225A, PU225S series. Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC. Coil Power: 20W, 12W, 13W, 22VA, 15VA. The solenoid coil is integral in the operation of a solenoid valve. It is what converts the electric current into a magnetic field which in turn allows the operation of the solenoid valve.

Dimension & Data of 0543 Solenoid Coil, Armature:

BRANDO Model	BB14542004
Ordering Code	0543
Voltage	220VAC, 110VAC, 24VDC, 12VDC
Power	20W, 12W, 13W, 22VA, 15VA
Other voltage and power can be customized
Connector	DIN43650A

armature dimension

BRANDO Model	BAPC214548001
Function	2 Way Normally Closed
Tube Material	Stainless Steel
Seal Material	NBR, EPDM, FKM

Ordering Code of 0543 Solenoid Coil:

Code No	Voltage	Frequency (Hz)	Power W/VA
113-030-0042	24VDC		2,0
113-030-0045	48VDC		2,1
113-030-0032	48VDC		1,6
113-030-0032	220VAC	50		6,4
113-030-0032	230VAC	50		6,6
113-030-0032	240VAC	50		5,7
113-030-0278	12VDC		6,0
113-030-0026	24VDC		6,1
113-030-0029	24VAC	50		10,8
113-030-0029	24VAC	60		9,6
113-030-0036	110VAC	50		11,1
113-030-0036	120VAC	60		11,7
113-030-0033	220VAC	50		10,8
113-030-0044	12VAC	50		19,3
113-030-0044	12VAC	50		17,1
113-030-0027	24VDC		11,0
113-030-0039	24VAC	50		17,9
113-030-0039	24VAC	60		15,6
113-030-0037	110VAC	50		17,6
113-030-0037	120VAC	50		18,3
113-030-0034	220VAC	50		18,1
113-030-0034	240VAC	60		18,9
113-030-0033	240VAC	50		11,4
113-030-0047	12VDC		15,0
113-030-0028	24VDC		15,0
113-030-0040	24VAC	50		21,8,
113-030-0040	24VAC	50		19.4
113-030-0043	48VAC	50		26,2
113-030-0043	48VAC	50		23,2
113-030-0052	48VAC	50		19,0
113-030-0052	48VAC	50		16,6
113-030-0038	110VAC	50		24,8
113-030-0049	110VAC	50		21,7
113-030-0049	110VAC	50		19,2
113-030-0038	120VAC	50		26,1
113-030-0041	195VDC		16,6
113-030-0035	220VAC	50		22,0
113-030-0050	230vAC	50		21,4
113-030-0050	230VAC	50		19,0
113-030-0031	240VAC	50		17,9
113-030-0035	240VAC	50		23,2

Video of 0543 Solenoid Coil:

BRANDO Solenoid Valve Coils Production Video:

More Solenoid Valves for you to choose:


PU220A Series	PU225A Series

SPU225A Series	PU225S Series

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!

Label:

Kontak Person: Mr. Brandon Bao

Tel: 86-13454729544

Faks: 86-574-83879820
