Name: 500 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 220V 110V 24V 12V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: H12S010B02
Price: 26.00 USD
Availability: InStock

Rumah Produk Katup Solenoid Stainless Steel

500 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 220V 110V 24V 12V

Detail produk:

Tempat asal:	Cina
Nama merek:	BRANDO
Sertifikasi:	None
Nomor model:	H12S010B02

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 buah
Harga:	Dapat dinegosiasikan
Kemasan rincian:	Kotak Dalam, Karton, Palet
Waktu pengiriman:	perundingan
Syarat-syarat pembayaran:	T/T, Western Union,
Menyediakan kemampuan:	100000 BUAH per bulan

Kontak

Detil Deskripsi produk

Nama Produk:	Katup Solenoid Tekanan Tinggi	Ukuran Pelabuhan:	G1/4''
Ukuran lubang:	1.0mm	Tekanan kerja maksimal:	500 batang
Fungsi:	2 Way Biasanya Tertutup	Bahan tubuh:	Baja Tahan Karat
Bahan Diafragma:	MENGINTIP	Voltase:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Menyoroti:	500 bar High Pressure Solenoid Valve , 50 MPa High Pressure Solenoid Valve , High Pressure Solenoid Valve 1/4''

500 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 220V 110V 24V 12V Technical Data: Model No Port Size Orifice Size (mm) Cv Working Pressure (bar) Body Seal NC/NO AC220V/ AC110V AC24V/ DC24V DC12V H12S008B02 G1/4'' 0.8 0.03 0 to 700 0 to 700 0 to 600 SS304 PEEK 2 Way NC H12S010B02 1 0.04 0 to 500 0 to 450 0 to 400 H12S015B02 1.5 0.08 0 to 360 0 to 300 0 to 250 H12S020B02 2 0.15 0 to 200 0 to 160 0 to 120 Main Dimension: Our Production: FAQ: Question 1: What is a

Label:

Kontak Person: Mr. Brandon Bao

Tel: 86-13454729544

Faks: 86-574-83879820
