Name: Solenoid Valve For Afiflo 2000 Milking System Electronic Digital Milk Meter
Brand: Ningbo Brando Hardware Co., Ltd
SKU: BB04450002
Price: 25.00 USD
Availability: InStock

Rumah Produk Katup Solenoid Plastik

Solenoid Valve For Afiflo 2000 Milking System Electronic Digital Milk Meter

Detail produk:

Tempat asal:	NINGBO, Tiongkok
Nama merek:	BRANDO
Sertifikasi:	None
Nomor model:	BB04450002

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	200
Harga:	Dapat dinegosiasikan
Kemasan rincian:	kotak batin, karton, palet
Waktu pengiriman:	perundingan
Syarat-syarat pembayaran:	T/T, PayPal, Western Union
Menyediakan kemampuan:	100000pcs per bulan

Kontak

Detil Deskripsi produk

Media Kerja:	Vakum, Udara, Susu	Bahan Diafragma:	Silikon
Ukuran Port Vakum:	8,3mm OD, 5mm ID	Ukuran Port Pembuangan Udara Bersih:	Diameter luar 8,3 mm, Kedalaman dalam 3,2 mm
Konektor:	Kabel 5 Meter (Standar)	Voltase:	24Vdc
Aplikasi:	Meter susu
Menyoroti:	AfiFlo 2000 solenoid valve , 24VDC solenoid valve for AfiFlo 2000 , AfiFlo 2000 milk meter solenoid valve

Solenoid Valve For Afiflo 2000 Milking System Electronic Digital Milk Meter The solenoid valve used for the Afikim AfiFlo 2000 milk meter is a specialized 24VDC pneumatic solenoid valve that controls the vacuum/air signal used to operate the milk-meter drain valve. It is not a conventional milk-contacting liquid solenoid valve. The AfiFlo 2000 shows that the milk-meter body contains a silicone diaphragm, cylindrical valve and solenoid valve. When the solenoid is energized,
